Type
Ducati V4 Granturismo, V4 - 90°, 4 valves per cylinder, counter-rotating crankshaft, twin pulse firing order, semi dry sump, liquid cooled
Displacement
1,158 cc (70.6 cu in)
Bore and stroke
83 mm x 53.5 mm (3.3 in x 2.1 in)
Compression Ratio
14.0:1
Power
170 hp (125 kW) @ 10,750 rpm
Torque
124 Nm (12.6 kgm, 91 lb ft) @ 9,000 rpm
Fuel injection
Continental electronic fuel injection system, Øeq 46mm equivalent elliptical throttle bodies with Ride-by-Wire system
Exhaust system
Stainless steel muffler, double catalytic converter and 6 lambda probes
Gearbox
6 speed with Ducati Quick Shift up/down 2.0
Primary drive
Straight cut gears; Ratio 1.8:1
Ratios
1=40/13, 2=36/16, 3=34/19, 4=31/21, 5=29/23, 6=27/25
Final drive
Chain, Front sprocket Z16; Rear sprocket Z42
Clutch
Multiplate clutch with hydraulic control. Self-servo action on drive, slipper action on over-run
Frame
Aluminium monocoque frame
Front suspension
Ø 50 mm fully adjustable USD fork, electronic compression and rebound damping adjustment with Ducati Skyhook Suspension, integrated stroke sensor.
Front wheel
Light alloy cast, 3" x 19"
Front tyre
Pirelli Scopion Trail II 120/70 R19
Real suspension
Fully adjustable monoshock, electronic adjustment with Ducati Skyhook Suspension, automatic fast lowering device between 10km/h and 50km/h, aluminium double-sided swingarm
Rear wheel
Light alloy cast, 4.5" x 17"
Rear tyre
Pirelli Scorpion Trail II 170/60 R17
Wheel travel
170 mm / 180 mm (6.7 in / 7.1 in)
Front brake
2 x Ø 330 mm semi-floating discs, radially mounted Brembo M50 Stylema monobloc 4-piston 2-pad calipers, radial master cylinder, Cornering ABS
Rear brake
Ø 280 mm disc, Brembo 2-piston floating caliper, Cornering ABS
Instrumentation
6.5" TFT colour display with Ducati Connect and full-map navigation system
Wet weight
240 kg (No Fuel)
Seat height
Adjustable, 870 mm - 890 mm (34,3in - 35in) 885 mm - 905 mm (34,8in - 35,6in) with high foam seat accessory 855 mm - 875 mm (33.7 in - 34.4 in) with mid/low foam seat accessory 825 mm - 845 mm ( 32,5in - 33,3in) with low foam seat accessory 805 mm - 825 mm (31,7in - 32,5in) with low foam seat + low suspension kit accessory
Wheelbase
1,566 mm (61.7 in)
Rake
24.2°
Trail
101 mm (4 in)
Fuel tank capacity
22 l (5.8 US gal)
Number seats
2
Safety equipment
Riding Modes, Power Modes, Ducati Traction Control (DTC), Engine Brake Control (EBC), Bosch Cornering ABS, Ducati Brake Light (DBL), Ducati Cornering Light, Ducati Vehicle Observer (DVO), Ducati Wheelie Control (DWC) DVO, Vehicle hold control , Radar system (Adaptive Cruise Control + Forward Collision Warning + Blind Spot Detection)
Standard equipment
Ducati Quick Shift (DQS) up/down 2.0, Ducati Skyhook Suspension, Coming Home, TFT colour display, Extended Cylinder Deactivation (ECD), Additional LED lights, Hands-Free, Hands-Free tank filler plug, Full LED lighting system, Daytime Running Light (DRL), Self cancelling turn indicators, Heated grips, Full-map navigation system, 12V socket, USB port, Backlit handlebar switches, Tyre Pressure Monitoring System (TPMS), Heated rider and passenger seats, Automatic fast lowering device, Rear Fog Light, Central stand, Plastic side panniers
Ready for
Anti-Theft
Warranty
48 months, unlimited mileage
Valve clearance check
60,000 km (37,000 mi)
Standard
Euro 5+
Co emissions
152 g/km
Consumption
6.6 l/100 km
Notes
* Without side panniers. Plastic side panniers weight 10,9 kg (24 lb)
